REFLEX ACTUATOR KIT – LP & XL

Introducing the Reflex Light Actuator™ (Patent Pending) – the first fully compatible actuator system designed exclusively for the Baja Designs light lineup. Born from racing in Baja, the Reflex brings professional race-level engineering to a consumer-ready solution. Engineered exclusively for our lights, the Reflex delivers instant, on-the-fly control of light pitch angle. Drivers can adjust their light up to 20 degrees depending on light type, ensuring perfect light coverage for every terrain change, climb, descent, or high-speed section. The Reflex mounts directly to existing Baja Designs light brackets with included hardware. No fabrication, no guesswork, just clean installation and plug-and-play setup. This actuator is compatible with the full LP Series and XL-M (shallow housing) lights. NOTE: Wiring harness sold separately.

Features:

• Low profile actuators allow users to adjust the pitch angle of lights through large range of motion on the fly.
• Mounts directly to existing Baja Designs universal brackets, for installation on new lighting packages or retrofitting existing lighting packages.
• Compatible with most VSKs using the light’s universal bracket.
• Standard Baja Designs Limited Lifetime Warranty.
• Wiring harnesses for control via rocker switch or power control modules (sPOD, SwitchPros, and others).
• NOTE: Wiring harness sold separately.

Specifications:

• 0.14A/2.0W at 13.8V per actuator
• MIL-STD-810G, IEC compliant
• Waterproof Rating: IP54

NOTE: Actuator Wiring Harness sold separately.
